IFS208 Inductive sensor IFKC004BASKG/M/US-104-DRS/2LED
IFS208
Inductive sensor
IFKC004BASKG/M/US-104-DRS/2LED
- Robust metal housing for use in harsh industrial environments
- Clearly visible indication of the switching status
- Operation as three-wire or two-wire possible
- Long sensing range for high uptime
- With optical mounting and setting aid
Description
| Electrical data | |
|---|---|
| Operating voltage [V] | 10…30 DC |
| Current consumption [mA] | 12; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
|
Outputs |
|
| Electrical design | PNP/NPN |
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.8 |
| Minimum load current [mA] | 2; (only in 2-wire operation) |
| Max. leakage current [mA] | 0.5; (only in 2-wire operation) |
| Permanent current rating of switching output DC [mA] | 100 |
| Switching frequency DC [Hz] | 500 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
|
Monitoring range |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Sensing range [mm] | 4 | ||||||||||
| Real sensing range Sr [mm] | 4 ± 10 % | ||||||||||
| Operating distance [mm] | 0…3.25 | ||||||||||
| Increased sensing range | yes | ||||||||||
|
Accuracy / deviations |
|||||||||||
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 | ||||||||||
| Hysteresis [% of Sr] | 3…15 | ||||||||||
| Switch-point drift [% of Sr] | -10…10 | ||||||||||
|
Operating conditions |
|||||||||||
| Ambient temperature [°C] | -25…70 | ||||||||||
| Protection | IP 67 | ||||||||||
|
Tests / approvals |
|||||||||||
| EMC |
|
||||||||||
| MTTF [years] | 1306 | ||||||||||
| UL approval |
|
||||||||||
|
Mechanical data |
|||||||||||
| Weight [g] | 31.1 | ||||||||||
| Housing | Threaded type | ||||||||||
| Mounting | flush mountable | ||||||||||
| Dimensions [mm] | M12 x 1 / L = 70 | ||||||||||
| Thread designation | M12 x 1 | ||||||||||
| Material | brass white bronze coated; sensing face: PBT | ||||||||||
|
Displays / operating elements |
|||||||||||
| Display |
|
||||||||||
| optical setting aid | yes | ||||||||||
|
Accessories |
|||||||||||
| Accessories (supplied) |
|
||||||||||
